Relämodul för digitalt dörrlås tedee
Kodpanel för tedee relämodul
Tekniska specifikationer
- Strömförsöjning: 12-24V AC / DC
- Strömförbrukning: < 1W
- Antal utgångar: 1
- Typ av utgångar: Relä
- Max load: 6A 24V AC 6A 24V DC
- Antal ingångar: 3
- Typ av ingångar: Logical, closed to COM
- Input: 12 - 24V AC / DC
- Galvanic isolation: Ja, optisk
- Inputs polarization: detected automatically
- Housing: made of polyurethane composition not containing halogens, self-extinguishing for thermal class B (130 °C)
- Kapsling / IP-klassning: IP20
- Mounting: in the flush-mounted box (deepen or double) in the receiver case.
- Signalöverföring: bi-directional, krypterad
- Wifi frekvensy: 2.4GHz
- Kommunikationsstandard: μWiFi, compatible with WiFi
- Kommunikationsstandard: Wi-Fi connection via a standard router
- Control output type: relay NC/NO
- Max 144VA @ 24V AC 144W @ 24V DC
- Mått: 39 x 39 x 22 mm
Förpackningsinnehåll
- tedee relämodul
$35.73
Ordinarie: $102.09
-65%Relämodul för digitalt dörrlås tedee—
$102.09
$35.73

Description
Kodpanel för tedee relämodul
Tekniska specifikationer
- Strömförsöjning: 12-24V AC / DC
- Strömförbrukning: < 1W
- Antal utgångar: 1
- Typ av utgångar: Relä
- Max load: 6A 24V AC 6A 24V DC
- Antal ingångar: 3
- Typ av ingångar: Logical, closed to COM
- Input: 12 - 24V AC / DC
- Galvanic isolation: Ja, optisk
- Inputs polarization: detected automatically
- Housing: made of polyurethane composition not containing halogens, self-extinguishing for thermal class B (130 °C)
- Kapsling / IP-klassning: IP20
- Mounting: in the flush-mounted box (deepen or double) in the receiver case.
- Signalöverföring: bi-directional, krypterad
- Wifi frekvensy: 2.4GHz
- Kommunikationsstandard: μWiFi, compatible with WiFi
- Kommunikationsstandard: Wi-Fi connection via a standard router
- Control output type: relay NC/NO
- Max 144VA @ 24V AC 144W @ 24V DC
- Mått: 39 x 39 x 22 mm
Förpackningsinnehåll
- tedee relämodul
